I. Core Product Advantages
1. Constant Temperature Anti-Crystallization, Ensuring Raw Material Quality
Accompanying thermal temperature control system for precise temperature regulation, completely solving the problem of formaldehyde low-temperature polymerization and caking. Conveying pipelines and reactor feed inlets are not easily blocked, resin synthesis formula is stable, and panel bonding quality is consistent.
2. Enclosed Nitrogen Seal Design, Reducing Raw Material Loss
Isolating air volatilization, reducing formaldehyde consumption by more than 10%, while eliminating pungent formaldehyde odor in the workshop and improving the working environment.
3. Anti-Corrosion & Durable, Not Easy to Leak
Stainless steel tank body + PTFE sealing structure, tolerating slow acidification corrosion of formaldehyde, no leakage risk during long-term use, smoothly passing safety supervision and environmental assessment acceptance.
4. Safety Interlock Explosion-Proof, Avoiding Hidden Dangers
High and low liquid level, overpressure automatic interlock protection, paired with flame arrester and explosion-proof breathing valve, eliminating tank area combustion and explosion risks, complying with hazardous chemicals storage specifications.
5. Linkable with Full Glue-Making Line Equipment
Discharge pipeline can be connected to filter, multi-stage homogenizing pump, and reactor to form a fully automatic feeding system, realizing automatic formaldehyde feeding without manual opening operation.
6. Flexible Non-Standard Customization
Capacity 5mxc2xb3~100mxc2xb3 customized on demand, can be equipped with stirring anti-precipitation mechanism and automatic unloading system.
II. Compatible Storage Media
37%~40% industrial formaldehyde aqueous solution (formalin), stable formaldehyde solution.
III. Application Industries
Wood-based panel glue-making factories for particleboard, MDF, plywood; urea-formaldehyde resin/phenolic resin chemical plants; coating additive production enterprises; fertilizer chemical raw material workshops.
IV. Complete Supporting Linkage Scheme
Formaldehyde storage tank xe2x86x92 Explosion-proof delivery pump xe2x86x92 Pre-filter xe2x86x92 Reactor xe2x86x92 Mechanical emulsification and homogenization equipment xe2x86x92 High-temperature cooling tower, constituting a complete closed-loop glue-making production line.
V. Optional Upgrade Configurations
1. Fully automatic feeding control system, automatically conveying formaldehyde according to reactor proportion;
2. Explosion-proof audible and visual alarm, toxic gas detector linked exhaust system;
3. CIP cleaning-in-place interface for regular cleaning of polymerization precipitates in the tank;
4. Winter anti-freezing and summer spray cooling dual protection structure.
VI. After-Sales Service
1. On-site survey of tank area site, issuing complete formaldehyde storage safety plan;
2. Factory hydraulic pressure test and air tightness test, with pressure vessel qualification documents attached;
3. On-site hoisting and welding, thermal insulation installation, integrated construction of waste gas system;
4. Whole machine warranty, year-round supply of original accessories such as nitrogen seal valves, breathing valves, and sealing gaskets.
